1. What are the forms of flow meters? There are many types of flow meters, which can be mainly divided into the following categories based on measurement principles and application scenarios. 1. Differential pressure flowmeter calculates flow rate by measuring the pressure difference caused by fluid obstruction during the flow process. Orifice flowmeter: simple in structure and widely used, but with significant pressure loss. Venturi tube flowmeter: with low pressure loss and high accuracy, commonly used for measuring high flow gases or liquids. V-cone flowmeter: Absolute flow requires low fluid conditions and good stability
2. Velocity based flow meter calculates flow rate by measuring the flow velocity of the fluid. Turbine flowmeter: High precision, fast response, suitable for clean liquids and gases. Electromagnetic flowmeter: measures conductive liquids without pressure loss and is not affected by fluid density or viscosity. Ultrasonic flowmeter: installed outside the pipeline, not in contact with the fluid, no pressure loss
3. Positive displacement flowmeter measures the flow rate by repeatedly filling and discharging the fluid in the measuring chamber. Elliptical gear flowmeter: With extremely high accuracy, it is commonly used for precise measurement of viscous liquids such as oil. Waist wheel flowmeter: suitable for medium and large diameter pipelines, can measure gases and liquids
4. Mass flowmeter directly measures the mass flow rate of fluids, without being affected by temperature and pressure changes. Coriolis mass flowmeter: It can directly measure mass flow rate with high accuracy, and can also measure density synchronously. Thermal mass flowmeter: suitable for measuring small gas flo
_600x400.jpg)
5. Open channel flowmeter is dedicated to measuring flow in open channels with free surfaces. Bacher tank: Calculate flow rate by measuring the liquid level height inside the tank. Weir plate: The flow rate is calculated by measuring the height of the water level flowing through the top of the weir plate.
2. What are the commonly used small flow gas flow meters? There are two types of small flow measurement: one is to measure the gas or liquid flowing through a small pipeline with high accuracy; Another method is to measure the flow rate of fluids with very slow flow rates. There are many commonly used gas flow meters suitable for measuring small flow rates, such as differential pressure, float type, vortex type, thermal type, etc. Some gas flow meters are suitable for measuring medium and large flow rates, as well as small flow rates, while others are specifically designed for measuring small flow rates.
1、 Differential pressure flowmeter. The differential pressure flowmeter suitable for measuring small flow rates is mainly the internal orifice plate differential pressure flow chamber pin flowmeter. There are several significant differences between this flow meter and a flow meter with a standard throttling device as the sensor. The first difference is in structure, where the built-in orifice plate integrates the sensor bucket wheel with the transmitter. The second difference is the pipe diameter, which is suitable for concealed orifice plates with a diameter of less than 50mm. The typical inner diameters of pipelines are 10mm and 20mm. The third difference is the accuracy, which can be ensured by the method of real flow calibration for concealed orifice plates. Afte
