What are the commonly used flow meters for sewage flow monitoring?

2. How to measure the sewage flow meter for the discharge outlet without a pipe

The sewage flow meter for the discharge outlet without a pipe can be measured by flow velocity measurement method, and the commonly used equipment is Doppler ultrasonic flow meter. Its measurement principle, applicable scenarios, and specific operating points are as follows: Measurement principle Flow velocity measurement method: Calculate the flow rate by measuring the flow velocity of sewage in the pipeline.

. Taking the Doppler ultrasonic flowmeter as an example, its probe emits a beam of ultrasonic waves obliquely upwards. When the ultrasonic waves propagate in the fluid, they will interact with impurities such as bubbles or particles in the fluid. Due to the consistency between impurities and water flow velocity, when ultrasonic waves come into contact with impurities, the reflected wave will produce a Doppler frequency shift Δ f, which is proportional to the flow velocity. By measuring the Doppler frequency shift Δ f, the flow velocity of the fluid can be calculated, and combined with the cross-sectional area of the pipeline, the flow rate of sewage can be obtained. The Doppler flowmeter is suitable for flow measurement in various full and non full pipe scenarios such as channels, waterways, sewers, and drainage networks, especially for measuring the discharge outlet of non full pipes. In the state of incomplete pipeline, the sewage liquid level in the pipeline does not fill the entire pipeline, and there is a free liquid level. However, the Doppler flowmeter can adapt to this cumbersome flow state and accurately measure the sewage flow rate. M

easurement step equipment selection flow range: Select the appropriate flow meter based on the actual flow situation of the pipeline, ensuring that the measurement range can cover the changes in actual flow. For example, if the sewage flow rate at the discharge outlet fluctuates within a small range, a flow meter with a smaller range can be selected to improve the accuracy of slag measurement; If there is a significant change in flow rate, a flowmeter with a wider range should be selected. Measurement accuracy: Select equipment with appropriate accuracy according to monitoring requirements. For some occasions with high requirements for monitoring sewage discharge, such as industrial wastewater discharge supervision, it is necessary to choose high-precision flow meters to ensure the accuracy of measurement results; For some occasions with relatively low precision requirements, such as preliminary monitoring of urban domestic sewage discharge, flow meters with slightly lower precision can be selected. Environmental adaptability: Consider the corrosion resistance and waterproof performance of the flowmeter. Wastewater usually contains various chemicals and impurities, which have strong corrosiveness. Therefore, it is necessary to choose flow meters made of corrosion-resistant materials, such as stainless steel, polytetrafluoroethylene, etc. At the same time, the flowmeter should have good waterproof performance to prevent damage in humid environments. Data transmission and monitoring function: Choosing a flow meter with data transmission and monitoring functions can achieve real-time monitoring and data transmission, facilitating data analysis and management. For example, some flow meters can transmit measurement data to th
