What are the types of pipeline flow meters?
There are various types of pipeline flow meters, and the common ones are as follows
1. Electromagnetic flow meters work based on Faradays law of electromagnetic induction, measuring the absence of moving parts and resistance parts inside the pipeline, and will not cause pressure loss to the fluid.
. 2. Vortex flowmeter can measure liquids with a certain conductivity, such as sewage, acidic and alkaline liquids, etc. By using the principle of fluid vibration, a blocking fluid is placed in the fluid to generate a regular vortex column, and the flow rate is measured by detecting the vortex frequency of the pin chain. Can be used for flow measurement of gases, vapors, and liquids, such as compressed air, natural gas, etc.3. Turbine flowmeter: When the fluid passes through the pipeline, it impacts the turbine blades, causing the turbine to rotate. Its speed is proportional to the flow velocity of the fluid, and the flow rate is calculated by measuring the turbine speed. Commonly used for flow measurement of clean liquids and gases, such as light petroleum products in the petroleum and chemical industries. Ultrasonic flow meters measure flow by detecting the time difference, phase difference, or frequency difference caused by the flow of ultrasonic waves in the fluid. It can measure various liquids and gases, especially suitable for flow measurement of large diameter and difficult to install pipelines.
5. Orifice flowmeter is installed in the pipeline with an orifice plate. When the fluid flows through the orifice plate, a pressure difference is generated before and after the orifice plate, and the flow rate is calculated by measuring the pressure di
2. What brand of gas flowmeter is good?
3. What is the main purpose of a compressed air flow meter?
A compressed air flow meter is mainly used to measure the instantaneous flow rate, cumulative bending flow rate, and gas parameters under working conditions of compressed air.. 1. Core measurement object • Volume flow rate: the air flow rate under standard operating conditions (20 ℃, 1atm) or actual operating conditions, usually measured in Nm ³/h or m ³/h. • Mass flow rate: calculated through temperature and pressure compensation, commonly used in kg/h per buried slag position. • Cumulative flow rate: used to calculate energy consumption or production, such as the total output of an air compressor. 2 Key parameter measurement • Pressure range: 0-1.6 MPa (for conventional industrial use) or special high-pressure models • Temperature range: -20 ℃~80 ℃ (for models with PT100 temperature sensors) • Accuracy level
1.5 level (economic type) or 1.0 level (high-precision type) 3 Typical application scenarios - Air compressor outlet flow monitoring - Pneumatic equipment gas consumption detection - Compressed sock source air pipe network balance debugging - Energy Management System (EMS) data acquisition 4. Technical implementation methods: Thermal mass flow meter (direct measurement of mass flow) Vortex flow meter (with temperature and pressure compensation) Ultrasonic flow meter (non-contact measurement) Note: GB/T 34036-2017 standard in 2023 stipulates that industrial gas flow meters must have Modbus RTU communication protocol.
