1. Request SAE standard

Now provide the full content of SAE J1401 standard; SAE J1401 is a testing standard for hydraulic brake hoses used in road vehicle hydraulic systems, and also specifies the standard methods for distinguishing between major manufacturers. This version of the standard is J1401-2003, and subsequent numbers specify the year in which the most recent standard modification was adopted. SAE J1401 standard English original text 1 ScopeThis SAE Standard specifies the performance tests and requirements for hydraulic brake hose assemblies used in the hydraulic braking system of a road vehicle. It also specifies the methods used for identification of the hose manufacturer. This document applies to brake hose assemblies made of a hose fabricated from yarn and natural or synthetic elastomers and assembled with metal end fittings for use with nonpetroleum-base brake fluids as specified in SAE J1703 and SAE J1705.The nominal internal diameter of the brake hose shall fall within one of the following values:a. 3.5 mm or less (1/8 in or less)b. 4 to 5 mm (3/16 in)2.References2.1 Applicable Publications—The following publications form a part of this specification to the extent specified herein. Unless otherwise indicated, the latest issue of SAE publications shall apply.2.1.1 SAE PUBLICATIONS—Available from SAE, 400 Commonwealth Drive, Warrendale, PA 15096-0001. SAE J1703—Motor Vehicle Brake FluidSAE J1705—Low Water Tolerant Brake Fluids2.1.2 ASTM PUBLICATION—Available from ASTM, 100 Barr Harbor Drive, West Conshohocken, PA 19428-2959.ASTM B 117—Method of Salt Spray (Fog) Testing2.1.3 ISO PUBLICATION—Available from ANSI, 11 West 42nd Street, New York, NY 10036-8002.ISO R147—Load calibration of testing mac

calibrated flow meter|rotameter flow meter

hines for tensile testing of steel2.2 Related Publications—The following publications are provided for information purposes only and are not a required part of this document.2.2.1 SAE PUBLICATIONS—Available from SAE, 400 Commonwealth Drive, Warrendale, PA 15096-0001.SAE J1288—Packaging, Storage, and Shelf Life of Hydraulic Brake Hose AssembliesSAE J1406—Application of Hydraulic Brake Hose to Motor Vehicles2.2.2 ISO PUBLICATION—Available from ANSI, 11 West 42nd Street, New York, NY 10036-8002.ISO 3996—Hydraulic brake hose assemblies—Non-Petroleum hose hydraulic fluid standard3. Definitions3.1 Brake Hose Assembly—A brake hose equipped with end fittings for use in a brake system.3.2 Brake Hose—A flexible conduit manufactured for use in a brake system to transmit and contain the fluid pressure medium used to apply force to the vehicle "s brakes.3.3 Brake Hose End Fitting—A coupling, other than a clamp, designed for attachment to the end of a brake hose.3.4 Permanently Attached End Fitting—A coupling designed for permanent attachment to the ends of a brake hose by crimping or swaging.3.5 Free Length—The linear measurement of brake hose exposed between the end fittings of a brake hose assembly while maintained in a straight position.3.6 Leaks, Burst—The loss of test fluid from the brake hose assembly other than by the designed inlet(s) and outlet (s).3.7 Cracking—The interruption of a surface due to environment and/or stress.3.8 Hose Internal Diameter—A dimensional description of the nominal inside diameter that is printed on the hose cover. This dimension is to be used to calculate the gage size for the constriction test.EXAMPLE—3 mm4. Performance TestsPerformance tests for hydraulic brake hose assemblies include all of the
