Coriolis Flow Meter Price: Budgeting considerations for high-precision instrumentation
Quick Answer: A DN15 Coriolis meter from Silver Instruments starts near USD 2,800. Larger DN50 units for custody transfer can exceed USD 12,000. Your budget must cover the transmitter, materials, certifications, and site commissioning. Send us your pressure (bar), temperature (°C), pipe size (DN), and flow range for a fixed quote.
What makes up the Coriolis flow meter price
Tube diameter is the biggest cost lever. A DN15 sensor handles 0.5 to 5 kg/h for pilot plants. A DN50 meter for 20,000 kg/h of crude oil in a truck loading bay costs three to four times more. Every step up in size increases the sensor material mass and transmitter power electronics.
Wetted material choice adds 40 to 60 percent. 316L stainless steel is the baseline for water, fuel oil, and mild chemicals. Hastelloy C-22 suits aggressive acids and solvents like nitric acid or bromine. A food grade tri-clamp connection with 316L can also add cost but simplifies CIP cleaning.
Transmitter features drive the second line on the quote. An integral 4-20 mA HART transmitter with PT100 temperature compensation fits most batching and dosing tasks. If you need density output, Modbus RTU, or Ethernet IP, expect a price increase of 10 to 15 percent. ATEX Zone 1 or IECEx certification can add another 20 percent because of extra testing and documentation. All Silver Instruments meters can be supplied with ATEX/IECEx tags.
Total cost of ownership beyond the invoice
Most engineers skip this part. Installation and cabling often cost USD 300 to 600 for a single DN25 meter in a chemical plant. We have seen a paint manufacturer in Thailand spend USD 500 on stainless steel support frames and shielded cable alone. Budget it early.
Zero calibration and commissioning take half a day. If you need a service engineer on site in East Africa or the Caribbean, plan USD 1,000 to 1,500. Silver Instruments offers free remote support via WhatsApp video, which saved one Colombian dairy plant a USD 1,200 site visit last quarter.
Maintenance is minimal because there are no moving parts. An in-situ verification with a reference weight or master meter costs around USD 250 per check. Many factories combine it with their annual ISO calibratio
Real project price examples from our inbox
A sulfuric acid dosing skid in Vietnam needed a DN15 SICOR-M with PT100, 4-20 mA HART, and 316L. Budget: USD 3,200 delivered to Ho Chi Minh City.
An edible oil plant in Mexico bought 12 DN40 meters with Tri-Clamp, remote Modbus transmitters, and preset density curves. The per-unit price was USD 5,600, much less than buying individual units because of volume assembly and testing.
For a diesel loading terminal in Oman, a DN80 SIL-capable meter with ATEX Zone 1, pulse output, and custody transfer approval came to USD 13,800. The client bundled 4 meters and saved 12 percent on total cost.
How to get an accurate quotation from Silver Automation Instruments
Tell us your fluid name, viscosity in cP, density range, minimum and maximum flow rate, pipe size (DN), temperature (°C), and pressure (bar). Add any certification needs (ATEX, IECEx, SIL). We return a commercial proposal, datasheet, and lead time within 24 hours. Contact us at:
Email: [email protected]
Tel: +86-25-68650347
Whatsapp: +86-25-52155837
WeChat: +86 15365082610
Browse the Coriolis flow meter series on flow-meter.com.au. For aggressive chemicals, request our SICOR-H line with Hastelloy sensors.
FAQ: Coriolis flow meter price
Q: What is the typical DN15 Coriolis price?
A: Between USD 2,800 and 4,500 depending on material and certification.
Q: Why pay more for Coriolis than a turbine meter?
A: Mass flow without density compensation, works with low-conductivity liquids below 5 µS/cm that challenge magnetic meters, no moving parts, and no straight pipe run requirement tend to lower lifetime costs in dosing and transfer applications.
Q: Should I budget extra for installation?
A: Yes, around USD 300 to 600 for DN15 to DN50 meters, more if you need on-site commissioning.
Q: Does ATEX certification increase the price?
A: Yes, typically 20 to 30 percent. We supply ATEX Zone 1 and 2 sensors and transmitters.
Q: How fast can I get a quote?
A: Email your process details to [email protected]. We reply with a full proposal within one working day.
