1. Technical parameters of integrated vortex flowmeter
1. Diameter: DN15-DN2002. Nominal pressure
1.6MPa, 2.5MPa, 4MPa. 3. Operating environment temperature range: -25 ℃~+130 ℃, -25 ℃~+250 ℃, -25 ℃~+300 ℃, guess search. 4. Accuracy: ± 1.0%. 5. Power supply: Internal power supply 3.6V lithium positive battery. External power supply+24VDC ± 10%
2. Integrated vortex flowmeter?
● It can accurately measure the flow rates of gases, liquids, and vapors over a wide range of flow rates without being affected by fluid physical properties. ● Not affected by temperature and pressure, not easy to block, not easy to get stuck, not easy to scale, resistant to high temperature and high pressure, ● Safe and explosion-proof, suitable for harsh environments ● No movable parts, no holes or gaps in the design, the product is wear-resistant, dirt resistant, does not require mechanical maintenance, and has a long service life. ● Adopting low-power high-tech, battery powered on-site display flowmeter, it can operate continuously for more than two years without electricity; ● Temperature and pressure compensation with integrated design; The current output is all electrically isolated, with good common mode interference suppression capability; Simultaneously display the flow value and cumulative flow value, without the need to switch between them. Adopting anti vibration probes to effectively eliminate the influence of external vibrations. The circuit adopts surface mount technology, with a compact structure and high reliability. ● Adopting a split type signal converter, with a maximum cable length of 10 meters. ● Wide range ratio of 20:1 ● The overall structure design of the instrument is reasonable, with a wide d
3. Why is temperature and pressure compensation necessary when measuring gas with a vortex flowmeter?
When measuring gas with a vortex flowmeter, temperature and pressure compensation is needed. The main reasons include the compressibility of the gas, ensuring measurement accuracy, and meeting the requirements of industrial applications. Specifically, the compressibility of the gas is as follows: the gas has a large intermolecular distance and strong compressibility, and its density is significantly affected by temperature and pressure. According to the ideal gas state equation ($PV=nRT $, where $P $is pressure, $V $is volume, $n $is the amount of substance, $R $is the molar gas constant, and $T $is temperature), when the amount of substance remains constant, changes in temperature and pressure will cause changes in gas volume and density. For example, when the pressure increases, gas molecules are compressed, the number of molecules per unit volume increases, and the density increases; When the temperature rises, the volume of the gas expands and the density decreases. This density change directly affects the accuracy of flow measurement. Image: Xiamen Jingchuan Integrated Vortex Flow Meter ensures measurement accuracy and differs from standard condition settlement: Gas is usually settled based on the volumetric flow rate under standard conditions (such as 0 ℃, 1 standard atmosphere), but the actual temperature and pressure during measurement are oft
