What media can flow meters be used to measure?
The question you raised is quite significant, because the type of flow meter used and the medium are only one factor, and other comprehensive factors such as pipe diameter, pressure, temperature, etc. need to be considered.. Regarding clamp on flow meters, only ultrasonic flow meters are available because their measurement is non-contact, while other flow meters are contact type and must be in contact with the medium. Therefore, there is no installation method of clamp on the outside of the pipe. In addition, there are many flow meters that can measure gases, such as orifice plates, vortex streets, waist wheels, turbines, ultrasonic waves, mass flow meters, and so on. And there are even more methods for measuring liquids, too many to list, almost all of which can be measured. Viscous liquids or particulate lead can be measured, but the specific type of flow meter used for measurement still depends on other factors. Common connection methods for flow meters In contemporary industry, it is often necessary to measure the flow rate of fluids for better monitoring and control of industrial processes. Therefore, flow meters have emerged, and different industrial development directions have led to various flow meters, such as rotor flow meters, turbine flow meters, electromagnetic flow meters, vortex flow meters, and so on. The connection method of each flowmeter is different. According to the customers requirements for slag handling, even for the same type of flowmeter, the connection method may not be the same. The design, selection, purchase, and maintenance costs of the flowmeter connection method are important factors in the use of the flowmeter. Next, Qin Wei
_600x400.jpg)
1. Flange connection: This connection method is the most commonly used. Electromagnetic flow meters, turbine flow meters, Roots flow meters, and so on all have this connection method. Just fix the flanges at both ends to the flanges on the pipeline with bolts.
.2. Threaded Connection: Some flow meters also use threaded connections, which are mostly used for pipe diameters smaller than DN50 and are commonly used in medical and food industries.
.3. Clamp on connection: This connection method is relatively simple and convenient. Weld the flange on the flowmeter to the pipeline, and then place the flowmeter between the two flanges and fix them with threads.
. Many vortex flowmeters use this connection method.Fourth, clamp connection: Nowadays, some small-diameter and low-pressure pipelines use this type of connection. Through this connection form, flow meters can be quickly installed and disassembled, and their daily cleaning and maintenance are also very convenient.
. For flowmeter manufacturers, communicating with customers is to do a good job in flowmeter selection, and at this time, they will definitely ask the other party what kind of connection method they need. In addition to being clear about the connection method, it is also important to understand the size of the flange and the standard size of the flange; What kind of thread, internal thread or external thread, how many inches of thread, etc. The correct choice of connection method is a prerequisite for ensuring the normal use of flow meters. To install a flow meter, the user needs to equip another pair of standard flanges welded to the
