1. What is the principle and function of a gas flowmeter? The core function of a gas flowmeter is to accurately measure the flow of gas in pipelines or equipment. Its working principle varies depending on the type of technology used, serving key fields such as industry, energy, environmental protection, and healthcare. 1. Working principle: Gas flow meters are designed based on different physical principles and are mainly divided into the following types: differential pressure flow meters are based on the Bernoulli principle. They measure the pressure difference before and after gas flow by installing throttling devices (such as orifice plates) inside the pipeline to calculate the flow rate. Thermal flow meters utilize the heat conduction effect. After the sensor is heated, the gas flow will take away its heat. The flow rate value is obtained by monitoring the corresponding relationship between temperature changes and flow rate. The vortex flowmeter places a blocking fluid in the flow channel, and alternating vortices are generated when gas flows through. The frequency is proportional to the flow velocity, and the detection frequency can be used to convert the flow rate. Positive displacement flowmeter divides gas into fixed volume units through mechanical structure, counts the number of units passed in a unit time, and accumulates the total flow rate. Its main function is to control the production process in industries such as chemical and power. Accurate gas flow measurement is the basis for ensuring reaction conditions, optimizing production efficiency, and stabilizing product quality. Energy measurement and trade settlement are widely used for measuring the consumption of energy gases such as natural gas, ensuring fair trade between supply and demand sides and effective energy management. The environmental monitoring and emission management department uses it to monitor the flow of exhaust gas emissions from enterprises, evaluate whether they meet environmental standards, and assist in environmental pollution control. The safe application of medical equipment in ventilators, anesthesia machines, and other devices accurately controls the gas flow delivered to patients, which directly affects the safety and effectiveness of treatment.

2. Which laboratory gas flowmeter should I look for?

3. Working principle of orifice flowmeter

An orifice flowmeter is a device that calculates gas flow by measuring pressure difference. Its core principle is based on energy conservation and flow continuity in fluid mechanics.. Here is a detailed explanation:

1. Working principle: When gas flows through an orifice plate, due to the sudden reduction in the cross-sectional area of the orifice plate, the gas flow velocity increases significantly at the orifice, while the pressure decreases. According to the Bernoulli equation, the kinetic energy and static pressure energy of a fluid are converted into each other, and an increase in flow velocity leads to a decrease in static pressure, thereby forming a pressure difference (Δ P) between the upstream (high-pressure side) and downstream (low-pressure side) of the orifice plate. The relationship between flow rate and pressure difference: Under stable flow conditions, the gas flow rate (qv) is proportional to the square root of the pressure difference (Δ P), that is: qv: gas volume flow rate (m3/min) K: orifice plate coefficient (determined by orifice plate geometry, gas pr
